Standards |
• |
IEEE 802.3 10Base-T Ethernet |
• |
IEEE 802.3u 100Base-TX Fast Ethernet |
• |
IEEE 802.3ab 1000Base-T Gigabit Ethernet |
• |
IEEE 802.3x Full Duplex Flow Control |
• |
IEEE 802.3af Power over Ethernet |
• |
IEEE 802.3at Power over Ethernet |
Physical Ports |
• |
8x Gigabit Ethernet 1000Base-T PoE ports |
Performance |
• |
Switching Capacity: 16Gbps |
• |
Forwarding Rate: 14880pps (Ethernet); 148800pps (Fast Ethernet); 1488000pps (Gigabit Ethernet) |
• |
MAC Address Table Size: 8K |
PoE Specifications |
• |
Maximum PoE power per port: 30 watts |
• |
Maximum PoE power per port (full load): 18.75 watts |
• |
Total PoE Power support by Switch: 150 watts |
• |
POE Pins: PoE delivered on pins 1, 2 (Power-); 3 and 6 (Power+) |
Mechanical Specifications |
• |
Form Factor: Desktop case |
• |
Dimensions: 280mm x 179mm x 44.5mm (W x D x H) |
• |
Weight: 1.5Kg (3.3lbs) |
• |
LED Indicators: System Power, LINK/ACT, POE |
• |
AC input: 100-240VAC internal power supply |
Environmental Specifications |
• |
Operating Temperature: 0°C - 40°C |
• |
Storage Temperature: -40°C - 70°C |
• |
Operating Humidity: 10%-90% non-condensing |
• |
Storage Humidity: 5%-90% non-condensing |
Certification |
• |
C-Tick, CE, FCC, RoHS |
